CDM-625 Advanced Satellite Modem
Front Panel Operation
Cold-Start
AFR
Xref
Ref-Adjust
Sync Clock
5.10.7.2 ODU: FSK-control
Monitor:
Tx
◄ ►
Use the arrow keys to select the parameters to monitor, then press ENTER.
ODU: FSK-control
Tx: SynTune = 09.6 VDC
Press ENTER or CLEAR to return to previous menu.
ODU: FSK-control
Rx: SynTuneE = 01.4 VDC
Press ENTER or CLEAR to return to previous menu.
ODU: FSK-control
Misc: Ref-Tune = 03.0 VDC
Press ENTER or CLEAR to return to previous menu.
If enabled, when the CSAT is powered on, the IF and RF outputs will remain
muted for 15 minutes.
(Auto Fault Recovery) This defines how a CSAT will react to momentary
fault conditions:
Off: CSAT will mute when faulted and remain muted.
On: CSAT will mute when faulted, but unmute after the fault goes away.
(External Reference) The CSAT will automatically lock to an external 5 or
10 MHz reference independent of the state of this selection. This selection
determines whether or not the Summary Fault Relay is activated if the CSAT
loses lock with the external reference.
The user may edit the Internal 10MHz Reference setting. The value will
scroll between 000 and 255.
NOTE: The Internal Reference is adjusted in the factory to be very accurate
with the default setting of 087. This parameter is made available to
compensate for the long-term frequency drift of the oscillator.
(Default is NO.) Selecting YES and pressing ENTER will cause the CSAT
RTC to be synchronized to the Modem RTC.
(2 CSATs)
Rx Misc Power-Supplies
(2 CSATs)
IFLO = 11.1 VDC
(2 CSATs)
IFLO = 11.2 VDC
(2 CSATs)
LNA = 00.05 mA
5–67
MN-0000036 (Ref MN/CDM625.IOM)
CSAT Monitor
(34)
CSAT Monitor
Power = <24 dBm
Temp = 26 C
CSAT Monitor
Temp = 26 C
CSAT Monitor
Fan = 550 mA
Revision 1
Tx
Rx
Misc
