CDM-625 Advanced Satellite Modem
Front Panel Operation

ODU: FSK-control

Info:
Press ENTER or CLEAR to return to previous menu.
5.10.8 ODU: FSK-control
KST Select:
Conguration
◄ ►
Use the arrow keys to select the menu option, then press ENTER.
5.10.8.1 ODU: FSK-control
KST Config:
◄ ►
Use the arrow keys to select the parameters to configure, then press ENTER.
ODU: FSK-control
Tx:Off
◄ ►
Use the arrow keys to select the parameter to edit, then use the
parameter. The user may edit Tx Frequency, Tx Attenuation, Amplifier setting, or AGC setting.
Press ENTER to implement, or CLEAR to cancel and return to the previous menu.
ODU: FSK-control
Rx: Freq=11950 MHz
Note: The RX Band is not shown for the KST-2000A.
Use the ◄ ► arrow keys to select the parameter to edit, then use the
parameter. The user may edit Rx Frequency, Rx Attenuation, Ref setting, or Rx Band (KST-
2000B only). Press ENTER to implement, or CLEAR to cancel and return to the previous menu.
(2 CSATs)
LNA:Off
Window:48%
KST
Information
KST
Tx Rx Miscellaneous
KST Configuration
Freq=13955 MHz
KST Configuration
Band=B
MN-0000036 (Ref MN/CDM625.IOM)
CSAT Information
Fault-Logic:Summary
Alarms (34)
Configuration
Tx
Att=23 dB
AGC=Off (34v)
Rx
Att=20 dB
5–70
LNA
(EC)
(34)
arrow keys to edit the
▲ ▼
Ref=087
(34)
arrow keys to edit the
▲ ▼
Revision 1
