CDM-625 Advanced Satellite Modem
Remote Control
D.7.3

Unit Parameters

Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Local/Remote LRS= 1 byte, 0 to 3
Status
Modem EMU= 1 byte, value
Emulation 0,1 or 2
Front Panel FPL= 1 byte,
Lockout numeric
Software IMG= 1 byte, value
Image of 1 or 2
Description of Arguments
Command or Query.
Used set the user's Local/Remote status, where:
0=Local
1=Serial Remote (RS-232/RS-485)
2=reserved
3=Ethernet Remote
Example: LRS=1 (which is Serial Remote)
Command or Query.
The CDM-625 is designed to be a 'drop-in' replacement for the
CDM-600 or CDM-600L modems. In order for complete modem
emulation, all parameters, including the EID(equipment ID) must be
that of the modem it is emulating. This parameter permits the CDM-
625 modem to be configured that way.
The format for the argument is x, where x is:
0= full capability CDM-625 modem (default)
1= to emulate the CDM-600 modem
2= to emulate the CDM-600L modem
Command or Query.
Control the state of front-panel lockout, where:
0= no lockout
1= front panel lockout active.
Disable the lockout by either FPL=0, or by setting into local mode
using LRS=0.
Command or Query.
Active software image, where:
1=Bulk Image #1 currently active
2=Bulk Image #2 currently active
D–24
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction Response to Query
Command
& Qualifier)
LRS LRS? LRS=x
LRS? (see description of
arguments)
LRS*
LRS#
EMU= EMU? EMU=x
EMU? (see description of
arguments)
EMU*
EMU#
FPL= FPL? FPL=x
FPL? (see description of
arguments)
FPL*
FPL#
IMG= IMG? IMG=x
IMG? (see description of
arguments)
IMG*
IMG#
Revision 1
