CDM-625 Advanced Satellite Modem
Remote Control
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Equipment
ID...
Description of Arguments
N=CnC data rate option, where
0=No CnC FAST installed
1=up to 512kbps
2=up to 1Mbps
3=up to 2.5 Mbps
4=up to 5Mbps
5=up to 10 Mbps
6=up to 15Mbps
7=up to 20Mbps
8=up to 25Mbps
P=Reserved data rate option, where
0=Base, up to 1Mbps
1=up to 2.5Mbps
2=up to 5 Mbps
3=up to 10Mbps
Q=Reserved option
(Decode shown above)
R=Framing option
0=Standard: (Unframed, EDMAC, EDMAC2)
1 = Option 0 plus
Open Network (IBS with hi-rate ESC, IDR, Audio)
S=D&I option
0=None
1=D&I,D&I++ for single port E1/T1
2=Option 1 plus Quad D&I (4 ports)
T= Reserved
0=Not installed, 1=installed on
U=Reserved
0=Not installed, 1=installed
V=Reserved
0=Not installed, 1=Reserved, 2=Reserved, 3=both
W=Reservedt option
0=Not installed
1=Reserved
2=Reserved
X=Reserved
0=None, 1=Reserved, 2 =Reserved, 3=both
Y=Reserved option
0=None, 1=Reserved 2=Reserved 3=both
ssssss = spares (0)
D–47
Revision 1
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction &
Response to Query
Command
Qualifier)
