Comtech EF Data CDM-625 Installation And Operation Manual page 305

CDM-625 Advanced Satellite Modem
Remote Control
D.7.5 Modem Information
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Hardware N/A 4 bytes
Revision
Software N/A 5 bytes
Revision
Firmware N/A 256 bytes
information
Serial Number N/A 9 bytes
Description of Arguments
Query only.
Unit returns hardware revision level of both main circuit cards,
where xx indicates the main (bottom) card, and y indicates the top
(modem) card.
Query only.
Unit returns the value of the internal software revision installed in
the unit, in the form of x.x.x
Example: SWR=1.0.3
Query only.
Unit returns firmware information.
B requests boot code information
Example: FRW=Boot: FW/12865-1-,1.1.1,04/01/07
Otherwise, FRW returns firmware information for image 1 or 2:
Example: FRW=1
Fw/12864-,1.1.1,04/01/07
Fw/12866-,1.1.1,04/01/07
Fw/12867-,1.1.1,04/01/07
Fw/12868-,1.1.1,04/01/07
Fw/12875-,1.1.1,04/01/07
Fw/12874-,1.1.1,04/01/07
Query only.
Indicates the modem 9 digit serial number.
Example: SNO=176500143
D–45
Revision 1
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
N/A HRV? HRV=xx.y
(see description of
arguments)
N/A SWR? SWR=x.x.x
(see description
of arguments)
N/A FRW?B FRW=xxx...xxx
FRW?1 (see description of
arguments)
FRW?2
N/A SNO? SNO=xxxxxxxxx
(see description of
arguments)
