CDM-600 Satellite Modem
Front Panel Operation
6.3.5.1

STORE/LOAD: OVERRIDE CONFIGURATION

CONFIGURATION: xx OVERRIDE: NO (YES/NO)
Select override using the [↑] [↓] arrow keys, then press ENTER.
6.3.6

UTILITIES

UTILITIES:
LAMP
Select the Utilities parameter using the [←][→] arrow keys, then press ENTER
6.3.6.1

UTILITIES: SET-RTC

EDIT REAL-TIME CLOCK:
TIME: 12:00:00
To edit the time and date settings of the REAL-TIME CLOCK, select the digit to be
edited using the [←][→] arrow keys, change the value of the digit using the [↑] [↓] arrow
keys, then press ENTER
IMPORTANT
6.3.6.2

UTILITIES: BRIGHTNESS

EDIT DISPLAY BRIGHTNESS: 100%
To edit the display BRIGHTNESS, use the [↑] [↓] arrow keys. Press ENTER when the
brightness is suitable. Note that the values of brightness that can be selected are 25%,
50%, 75% or 100%.
SET-RTC
1:1-MANUAL-SWITCH
Note that in accordance with international convention, the date is
shown in DAY-MONTH-YEAR format.
DISPLAY-BRIGHTNESS
EDIT-CIRCUIT-ID
DATE: 24/04/01
6–40
Revision 7
MN/CDM600.IOM
.
