CDM-625 Advanced Satellite Modem
Ethernet Management
6.5.4.3.4
Config | Utilities
The 'Config | Utilities' page (Figure 6-9) is used to configure the following CDM-625 utility
functions:
Unit
o Test Mode, Sats Sample Interval, Front Panel Lockout, RTS/CTS Control, and HSSI
Handshake Control.
Once the desired configuration settings have been made in this section, the user should
then click [Submit Unit Utilities] as needed to save those changes.
Clocks
o Tx / Rx Clock Sources, Rx Buffer Size, External Clock, External Frequency Reference,
G.703 Clock Extended Mode / Interface.
Once the desired configuration settings have been made in this section, the user should
then click [Submit Clocks] as needed to save those changes.
Circuit ID
o The user may enter a Circuit ID string of up to 40 characters. Once the desired string had
been entered in this section, the user should then click [Enter Circuit ID] as needed to
save this change.
Figure 6-9. Config | Utilities page
6–16
MN-0000036 (Ref MN/CDM625.IOM)
Revision 1
