CDM-625 Advanced Satellite Modem
Remote Control
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Equipment ID
N/A
33 bytes
Description of Arguments
Query only.
Unit returns the equipment ID and installed options, where:
AAAA=0625 , the modem model number
Installed hardware:
B=Slot 1: TPC/LDPC codec
0 = not present, 1=present
®
C=Slot 2: DoubleTalk
Carrier-in-Carrier
0 = not present, 1=present
D=Slot 3: Advanced FEC
0 = not present, 1=Reserved, 2=Reserved
E=Slot 4: Reserved
0 = not present, 1=present
F=Slot 5: Reserved
0 = not present, 1=present
G=External 20dB attenuator
0 = not present, 1=present
ss=spares (0)
Software FAST options:
J=Frequency option
0=70/140MHz, 1= 70/140MHz & L-band
K=Modulation option
0=Standard: BPSK, QPSK, OQPSK.
1=Option 0 plus 8-PSK and 8-QAM
2=Option 0 plus 16-QAM
3=Option 1 and option 2
L=Data Rate option
M=TPC/LDPC data rate option
For L, M, and Q, the value is decoded:
0=Base, up to 5Mbps
1=up to 10Mbps
2=up to 15 Mbps
3=up to 20Mbps
4=up to 25Mbps
D–46
MN-0000036 (Ref MN/CDM625.IOM)
Response to
Command
N/A
®
board (CnC)
Revision 1
Query
(Instruction &
Response to Query
Qualifier)
EID?
EID=AAAABCDEFGss
JKLMNPQRSTUVWX
Yssssss
(see description of
arguments)
