TALKBACK AND REVERSE TALKBACK

Talkback is the process of routing a microphone to an output for the purpose of communication. Usually, talkback
routes a microphone signal to headphones or a loudspeaker so that people in a control room can talk to those on
the studio floor, and vice versa.
The talkback feed can be routed to any bus or output using either the touch display talkback buttons or the physical
surface talkback buttons. All talkback buttons are momentary, meaning they are only operational when held.
When talkback is routed to an output, the output's normal feed is entirely replaced by the talkback microphone feed.

Touch Display Talkback Buttons

There are talkback buttons for individual bus outputs in the Buses & Outputs window and for outputs in the mix minus
and direct output routing windows. Holding any of the touch display talkback buttons routes the talkback feed to the
corresponding output.

Surface Talkback Buttons

Each fader on the Summa surface has a talkback button at the top of the fader strip. Pushing and holding these surface
talkback buttons routes the talkback feed to the relevant output.
Note, pushing a group or channel input's talkback button routes talkback to the corresponding mix minus output.

Patching to Talkback

There is one talkback input to the system which is available as a patching destination within the I/O Patching screen.
Summa has a built-in talkback microphone situated close to the Summa logo on the surface, which is connected directly
to an XLR output on the rear of the surface. To use the built-in talkback microphone, first connect its output to any
Hydra2 I/O box input.
Any Hydra2 input port can be patched to the talkback input:
1. Tap I/O PATCHING in the Show menu.
2. Select I/O BOXES in the sources window and select the I/O box to which your talkback microphone is connected.
3. Select DESK CONNECTIONS within the destinations window and select talkback Inputs.
4. Tap to select the input port to which you have connected your talkback microphone.
5. Tap to select the talkback input.
6. Tap CONNECT.
The input settings, gain and 48 V, can be setup by the network administrator via H2O (see 'Source Settings' in the H2O
user guide for more information).
