Trackball,
Computermouse
Keyboard
Keyboard drawer
Board housing
Backup cue card
Powersupply
DMX 512 output
6 6 6 6 6
MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de

1.2 Specifications and extras

The basic MA SCANCOMMANDER is delivered as a 19" version with 1
desklamp. With this configuration it can perform all functions except labelling
your scenes and presets in the display. There is a list of options available that
will fit your needs.
Makes it easy to control movements. All Atari compatible trackballs or mice
can be used. Note: PC compatible mice cannot be used !!
Enables you to label your programs. Any PC-MF keyboard will work. American
keyboards may cause some problems by exchanging different letters.
(>>Memory Names, Preset Names)
The keyboard, offered by MA, can be mounted in a drawer underneath the
SCANCOMMANDER
Wooden sides and a front armrest are available.
All programs can be stored on a memory card in addition to the internal
storage. Cards from 32 to 256 kilobyte, type ITT STAR CARD S-RAM can be
used.

1.3 Installation

100-240 Volt, 40-60 Hz via Euro plug. No switching of voltage necessary.
According to USITT DMX 512 (1990) protocol. The output is opto insulated and
even better than RS 485 or RS 422. The pins in the 5 pin XLR plug are: Pin 1:
ground, Pin 2: Data-, Pin 3: Data+ (Pin 4 and 5: not used)
Other in- and outputs see chapter 9.
