Special regulations on
stage oriented movement
! Attention !
! Attention !
Direct setting of the
working mode
Changing the working
mode can be done by
recalling according
playbacks
eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Scancommander
- During stage oriented movement mode the value in the display reaches from
-99 to +99. The centre of the stage corresponds to 0/0, the corners have values
of +/-25. Values outside +/- 25 mean, that the beam is actually outside the
stage.
- When a preset is recalled with a x-fade time greater than zero, the beams will
change slowly and with a linear travel from their actual position to the new one.
- If the movement initialization was done correctly, any combination of scans,
which shows the same values in the display, meet the same point on stage.
Outside the stage, this effect will loose its accuracy.
Programming presets for Pan/Tilt makes movement control very handy.
44 positions on stage can be preprogrammed and recalled by their button.
In addition it helps to return to a well defined point if the operation via trackball
gets confusing.
During any programming of positions make sure, that the circle radius is set to
zero. If only the circle speed is zero, but the radius is greater zero, there is no
circle movement visible, but the radius is still valid and will cause an offset on
the programmed positions.

3.3.2 Changing the movement mode

OPTION button
keep button pressed and simultaneously press
SET SELECTION TO STAGE MOVEMENT
SET SELECTION TO DMX MOVEMENT
The actual mode is marks by "S" or "D" for all 16 scans. Changing the mode
via option cancels all running fades.
The working mode is stored within any preset, memory, chaser or sequence
step. The playback of this programs automatically restores the according
working mode. Fades between two positions with different working mode
always run in DMX direct mode.
SCAN SELECTION
Selection of the scans to be changed
selected scans, which work on direct DMX mode, will
swap to the stage calculation mode and jump to "00
00" middle of stage.
selected scans swap to direct DMX mode without
changing their position.
