Sequence playback with
adjusting rate via fader
Triggering a sequence via
Sound input
Manual x-fade step to step
(from version 1.40)
44 44 44 44
44
MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de

6.2.2 Playback of a sequence with adjusted step rate

RATE Fader
"SET RATE" Step Mode selected
SEQUENCE button 1-16

6.2.3 Playback of a sequence triggered by sound input

On the backpanel the SCANCOMMANDER offers a 1/4"jack for sound signal
input. The 3 potentiometers on the top of the front panel can be used to select
a trigger signal. The HOLD LED shows the trigger signal leaving the filter as it
is triggering the sequence.
SEQUENZ button 1-16
"EXT SOUND" Step Mode selected

6.2.4 Manual x-fade between sequence steps

X-FADER has to be moved to one of the end positions.
SEQUENZ button 1-16
"MAN FADE" Step Mode selected
X-FADE fader at the sequence section
Sets the sequence speed between 0.1 and 10 sec-
onds per step. The yellow LED inside the SET RATE
button shows the selected speed.
(red LED on)
The first step will be recalled as soon as the se-
quence button is pushed. All other steps will follow
automatically with the adjusted time.
(red LED on) The steps of the sequence is recalled
by the sound input.
(red LED on)
Moving the fader will fade between the steps. As soon
as the fader reaches the end of its travel, the next
step will be loaded for x-fade.
Moving back before the end of its travel is reached
will return the output to the last scene.
