Modifying memories,
basic structure
Changing memory
parameters
Modifying single channel
values or the matrix
selection
eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Scancommander

4.4 Modifying of memories

A stored memory contains data for:
All these data can be modified without starting from the very beginning.

4.4.1 Changing names and parameters

EDIT button
Memory button
Changing the memory parameters only will not recall this memory to stage.

4.4.2 Changing matrix and data

EDIT button
Memory button
MODIFY button
EDIT MATRIX
Feature button
1.x STORE button
2.x STORE button
The STORE MATRIX of the last modified memory stays in the temporary
storage and will be reconstructed when doing the next store operation.
- Name, x-fade time and trigpoint
- Matrix with trig/fade marks for the features
- Data for the single channels
the LED inside this EDIT button is on as long as the
edit mode is active.
Memory name, x-fade time and trigpoint can be set
via keyboard and encoder. Select the next memory or
cancel edit mode by switching off the edit button
(also possible by quit or any direct access.)
The selected memory gets recalled to stage and the
block "MODIFY" is displayed inverted.
Edit Matrix has to be inverted, if the STORE MATRIX
has to be checked or modified within the next steps.
SCAN selection
Preset button or Encoder
Channel values can be modified via direct
access.
Shows the STORE MATRIX of the selected memory.
Selection of channels and trig/fade marks can be
modified.
Saves the modified memory.
