Working mode of

selective memories

A small copy of
this matrix will be
displayed during the next
step and during any edit
or modify operation.
Selecting single channels
in the STORE MATRIX
eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Scancommander
4.3 Selective memories
Memories and scenes may be programmed in a way, that they only affect
selected channels. When this memory is recalled by its button, all other
channels stay untouched.
Example: a memory may be supposed to recall only a new color for scan
numbers 1 to 6. The position of the beams, the gobos and all other functions
stay unchanged, when this memory is recalled. Scan no.7 to 16 stay com-
pletely untouched.

4.3.1 Programming of selective memories

The STORE MATRIX, displayed any time the STORE button is pushed to save
a picture, marks out, which of the channels will be controlled by this scene.
STORE button
SCAN No: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
SHUTT
IRIS
FOCUS
R-G-B
PRISMA
COLOR
DIMMER
GOBO
MOVE
CIRCLE
SPEED
ROTAT.
EXTRA 1
EXTRA 2
Unlike programming standard memories, on programming selective memories
only a part of the channels are selected.
FEATURE button
( )
CLEAR button in the FEATURE block
The further procedure of storing selective memories is the same as storing
standard memories.
The modified STORE MATRIX is saved internally and reconstructed as soon as
the next STORE operation starts.
SCAN Selection
Selects the scans which will be affected by the
following feature
.
For the actual selection of scans, this feature is
selected. Selected channels are displayed inverted.
Changing the scan selection before pushing the next
feature button enables you to select any free
combination of channels.
Clears the complete matrix. The second CLEAR will
select all features for the selected scans. The third
CLEAR selects all features for all scans.
