Enable Traps
NMS #1 (or #2)
Location
Contact

Communities

Read-Only
Read-Write
Trap
Enable v1/v2
Alarm Delay

Version 3

Security
Auth with
Encrypt with
SLC™ 8000 Advanced Console Manager User Guide
Traps are notifications of certain critical events. Disabled by default. This feature is
applicable when SNMP is enabled. Examples of traps that the SLC 8000 advanced
console manager sends include:
Ethernet Port Link Up

Ethernet Port Link Down

Authentication Failure

SLC Booted

SLC Shutdown

Device Port Logging

Power Supply Status

Sysadmin user password changed

The SLC unit sends the traps to the host identified in the NMS field.
When SNMP is enabled, an NMS (Network Management System) acts as a central
server, requesting and receiving SNMP-type information from any computer using
SNMP. The NMS can request information from the SLC 8000 advanced console
manager and receive traps from the SLC unit. Enter the IP address of the NMS server.
Required if you selected Enable Traps.
Physical location of the SLC 8000 advanced console manager (optional). Useful for
managing the SLC unit using SNMP. Up to 20 characters.
Description of the person responsible for maintaining the SLC 8000 advanced console
manager, for example, a name (optional). Up to 20 characters.
A string that SNMP agent provides. The default is public.
A string that acts like a password for an SNMP manager to access the read-only data
from the SLC unit SNMP, like a password for an SNMP manager to access the read-
only data the SLC SNMP agent provides, and to modify data where permitted. The
default is private.
The trap used for outgoing generic and enterprise traps. Traps sent with the Event
trigger mechanism still use the trap community specified with the Event action. The
default is public.
If checked, SNMP version 1 and version 2 (which use the Read-Only and Read-Write
Communities) is enabled. Uncheck to only allow the more secure version 3 to be used
to access the SLC 8000 advanced console manager via SNMP. The default is
enabled.
Number of seconds delay between outgoing SNMP traps.
Levels of security available with SNMP v. 3.
No Auth/No Encrypt: No authentication or encryption.

Auth/No Encrypt: Authentication but no encryption. (default)

Auth/Encrypt: Authentication and encryption.

For Auth/No Encryp or Auth/Encrypt, the authentication method:
MD5: Message-Digest algorithm 5 (default)

SHA: Secure Hash Algorithm

Encryption standard to use:
DES: Data Encryption Standard (default)

AES: Advanced Encryption Standard

