Host Lists - Lantronix SLC 8000 User Manual

Dial-back Retries
Timeout Logins
Negotiate IP Address
Authentication
CHAP Handshake
CHAP Auth Uses
Enable NAT
Dial-out Number
Remote/Dial-out Login
Remote/Dial-out
Password/ Retype
Restart Delay
6. Click Apply.

Host Lists

A host list is a prioritized list of SSH, Telnet, and TCP hosts available for establishing incoming
modem connections or for the connect direct command on the CLI. The SLC unit cycles
through the list until it successfully connects to one.
To add a host list:
1. Click the Devices tab and select the Host Lists option. The following page displays:
SLC™ 8000 Advanced Console Manager User Guide
For dial-back and CBCP Server, the number of times the SLC unit will retry the
dial-out portion of the dialing sequence if the first attempt to dial-out fails.
If you selected text mode, you can enable logins to time out after the
connection is inactive for a specified number of minutes. The default is No. This
setting only applies to text mode connections. PPP mode connections stay
connected until either side drops the connection. Disabled by default.
If the SLC and/or the serial device have dynamic IP addresses (e.g., IP
addresses assigned by a DHCP server), select Yes. This is the default.
If the SLC unit or the modem have fixed IP addresses, select No, and enter the
Local IP (IP address of the internal modem) and Remote IP (IP address of the
modem).
Enables PAP or CHAP authentication for modem logins. PAP is the default.
With PAP, users are authenticated by means of the Local Users and any of the
remote authentication methods that are enabled.
With CHAP, the CHAP Handshake fields authenticate the user.
The Host/User Name (for UNIX systems) or
Secret/User Password (for Windows systems) used for CHAP authentication.
May have up to 128 characters.
For CHAP authentication, determines what is used to validate the CHAP host/
user sent by the remote peer: either the CHAP Host defined for the modem, or
any of the users in the Local Users list.
Select to enable Network Address Translation (NAT) for dial-in and dial-out
PPP connections on a per modem (device port, USB port, or internal modem)
basis. Users dialing into the SLC unit access the network connected to Eth1
and/or Eth2.
Note: IP forwarding must be enabled on the Network - Settings page for NAT
to work.
Phone number for dialing out to a remote system or serial device. May have up
to 20 characters. Any format is acceptable.
User ID for authentication when dialing out to a remote system, or if a remote
system requests authentication from the SLC module when it dials in. May have
up to 32 characters.
Password for authentication when dialing out to a remote system, or if a remote
system requests authentication from the SLC unit when it dials in. May have up
to 20 characters.
The number of seconds after the timeout and before the SLC module attempts
another connection. The default is 30 seconds.
8: Device Ports
130
