2. If desired, enter the following:
Reset to Default
Certificate
Import SSL Certificate To import your own SSL Certificate, select the checkbox. Unselected by default.
Import via
Certificate Filename
Key Filename
Passphrase /
Retype Passphrase
Host
Path
Login
SLC™ 8000 Advanced Console Manager User Guide

Figure 7-13 SSL Certificate

To reset to the default certificate, select the checkbox to reset to the default
certificate. Unselected by default.
From the drop-down list, select the method of importing the certificate (SCP,
SFTP, or HTTPS). The default is SCP.
Filename of the certificate.
Filename of the private key for the certificate.
Enter the passphrase associated with the SSL certificate if the private key is
encrypted.
Host name or IPaddress of the host from which to import the file.
Path of the directory where the certificate will be stored.
User ID to use to SCP or SFTP the file.
7: Services
97
