2. Enter the following:

Device Port Settings

Port
Mode
Name
Group Access
Banner
Break Sequence
View Port Log Seq
View Port Log
Zero Port Counters
Logging
Connected to

IP Settings

Telnet In
SSH In
TCP in
Port
SLC™ 8000 Advanced Console Manager User Guide
Displays number of port; displays automatically.
The status of the port; displays automatically.
The name of the port. Valid characters are letters, numbers, dashes (-), periods,
and underscores ( _ ).
If undefined, any group can access the device port. If one or more groups are
specified (groups are delimited by the characters ' ' (space), ',' (comma), or ';'
(semicolon)), then any user who logs into the device port must be a member of one
of the specified groups, otherwise access will be denied. Users authenticated via
RADIUS may have a group (or groups) provided by the RADIUS server via the
Filter-Id attribute that overrides the group defined for a user on the SLC unit. A
group provided by a remote server must be either a single group or multiple groups
delimited by the characters ' ' (space), ',' (comma), ';' (semicolon), or '=' (equals) -
for example "group=group1,group2;" or "group1,group2,group3".
Text to display when a user connects to a device port by means of Telnet, SSH, or
TCP. If authentication is enabled for the device port, the banner displays once the
user successfully logs in. Blank is the default.
A series of one to ten characters users can enter on the command line interface to
send a break signal to the external device. A suggested value is Esc+B (escape
key, then uppercase "B" performed quickly but not simultaneously). You would
specify this value as \x1bB, which is hexadecimal (\x) character 27 (1B) followed
by a B.
The key sequence used to view the Port Log while in Connect Direct mode. Non-
printing characters can be specified by giving their hexidecimal code (see Break
Sequence above). The default is Esc+V (\x1bV).
Select to allow the user to enter the View Port Log Sequence to view the Port Log
during Connect Direct mode. The default is disabled.
Resets all of the numerical values in the Port Counters table at the bottom of the
page to zero (0).
Click the Settings link to configure file logging, email logging, and local logging.
The type of device connected to the device port. Presently, the SLC 8000
advanced console manager supports Lantronix SLP Power Manager (SLP8
SLP16) ServerTech CDUs and Sensorsoft devices. If the type of device is not
listed, select undefined.
If you select anything other than undefined, click Device Commands. The
appropriate web page displays.
Enables access to this port through Telnet. Disabled by default.
Enables access to this port through SSH. Disabled by default.
Enables access to this port through a raw TCP connection. Disabled by default:
Note: When using raw TCP connections to transmit binary data, or where the
break command (escape sequence) is not required, set the Break Sequence of
the respective device port to null (clear it).
Automatically assigned Telnet, SSH, and TCP port numbers. You may override
this value, if desired.
8: Device Ports
