Log Viewing Attributes

Display
Number of Lines

NFS File Logging

NFS File Logging
NFS Log to View
Directory to Log to
Max Number of Files
Max Size of Files

USB / SD Card Logging

USB / SD Card
Logging
Log to View
Log To
Max Number of Files
Max Size of Files

Syslog Logging

Syslog Logging
Note:
Note: To apply the settings to additional device ports, in the Apply settings to
Device Ports field, enter the additional ports, (e.g., 1-3, 5, 6)
3. To apply settings to other device ports in addition to the currently selected port, select the
Apply settings to Device Ports and enter port numbers separated by commas. Indicate a
range of port numbers with a hyphen (e.g., 2, 5, 7-10), and separate ranges with commas.
4. To save, click the Apply button.
SLC™ 8000 Advanced Console Manager User Guide
Select to view either the beginning (Head) or end (Tail) of the log.
Number of lines from the head or tail of the log to display.
Select the checkbox to log all data sent to the device port to one or more files on an
external NFS server. Disabled by default.
Available log files in the selected NFS Directory to view.
The path of the directory where the log files will be stored.
Note:
This directory must be a directory exported from an NFS server mounted on
the SLC 8000 advanced console manager Specify the local directory path for the
NFS mount.
The maximum number of files to create to contain log data to the port. These files
keep a history of the data received from the port. Once this limit is exceeded, the
oldest file is overwritten. The default is 10.
The maximum allowable file size in bytes. The default is 2048 bytes. Once the
maximum size of a file is reached, the SLC unit begins generating a new file.
Select to enable USB / SD card logging. A USB thumb drive or SD card must be
loaded into one of the ports of the SLC and properly mounted. Disabled by default.
Available log files in the selected USB / SD card slot to view.
Select the USB port or SD card to use for logging.
The maximum number of files to create to contain log data to the port. These files
keep a history of the data received from the port. Once this limit is exceeded, the
oldest file is overwritten. The default is 10.
The maximum allowable file size in bytes. The default is 2048 bytes. Once the
maximum size of a file is reached, the SLC 8000 advanced console manager
begins generating a new file. The default is 2048 bytes.
Select to enable system logging.
Note:
The logging level for the device ports log must be set to Info to view Syslog
entries for Device Port logging on the
Services > SSH/Telnet/Logging
8: Device Ports
page.
123
