To view or update a host list:
1. In the Host Lists table, select the host list and click the View Host List button. The list of hosts
display in the Hosts box.
2. View, add, or update the following:
Host List Id
Host List Name
Retry Count
Authentication

Host Parameters

Host
Protocol
Port
SLC™ 8000 Advanced Console Manager User Guide

Figure 8-13 View Host Lists

Displays after a host list is saved.
Enter a name for the host list.
Enter the number of times the SLC 8000 advanced console manager should attempt to
retry connecting to the host list.
Select to require authentication when the SLC unit connects to a host.
Name or IP address of the host.
Protocol for connecting to the host (TCP, SSH, or Telnet).
Port on the host to connect to SLC advanced console manager
8: Device Ports
133
