CONCEPT IQ. PLUS Programmer's Manual.
Door Forced and DOTL system inputs will turn on the fault light on the Terminal and LEDs
15 or 16 when a NEXT 13 is performed. (Refer System Inputs)

3.1 INTRODUCTION.

THE PROGRAMMING KEY.

The Concept IQ Programming Key is a portable non-volatile memory device housed in a
convenient "key tag".
The Programming Key allows system programming to be uploaded from the Control
Module or downloaded to the Control Module by simply inserting the Programming Key
into Serial Port 0 and performing a simple key sequence on the LED Terminal. See below.
A built-in Lamp (embedded in the plastic surface) on the Programming Key visually
indicates when data transmission is active.
CONCEPT IQ PROGRAMMING KEY & FLASH INTERFACE.
This device allows the Programming Key to be connected to a PC for transferring Panel
data to and from the Upload/Download software.
NOTE: The Concept IQ Programming Key & Flash Interface can also be used to connect
a PC to the "Flash" connector (JP8) on the Controller for the purpose of providing a Flash
Upgrade of the Controller Firmware version.
Refer to your Concept IQ distributor for more details.
3.2 IMPORT DATA FROM THE PROGRAMMING KEY.
This Mode allows the Installer to copy the programming contents of the Programming Key
into the Control Module.
The Zones Inputs on terminals are used for door reed switch (zone1) and REX button
(zone2). Each zone must be fitted with the required device or, if not used, must be termi-
nated with 6k8 resistors. These Zones cannot be used for security zones.
3. PROGRAMMING KEY
IMPORTANT NOTE: The new data will override the existing contents of the Control
Module memory.
Connect the Programming Key to Serial Port 0 on the Control Module.
Select the Import Data Mode:
Enter PIN;
The Lamp on the Programming Key will flash slowly to indicate data is being copied.
The Terminal beeper will sound 3 short beeps if the operation was successful, or 1 long
beep if unsuccessful.
3.3 EXPORT DATA TO THE PROGRAMMING KEY.
This Mode allows the Installer to copy the programming contents of the Control Module into
the Programming Key.
IMPORTANT NOTE: The Control Module data will override the existing contents of the
Programming Key.
Connect the Programming Key to Serial Port 0 on the Control Module.
Select the Export Data Mode:
Enter PIN;
The Lamp on the Programming Key will flash quickly to indicate data is being copied.
The Terminal beeper will sound 3 short beeps if the operation was successful, or 1 long
beep if unsuccessful.
... , then , then the Mode number;
... , then , then the Mode number;
Ver. 3.003 p9
, , .
, , .
