Pulse Counting; Siren Output To Operate As An Auxiliary; Six Digit Pin Codes - Inner Range CONCEPT IQ. PLUS Programmer's Manual

p40 Ver. 3.003 (24/4/03)

PULSE COUNTING

1) Enable Pulse Count operation for any Zone Inputs that are to be used as "Pulse Count Zones".
Enable Option 4 - "Pulse Count" in the Zone Options.
2) Program the Pulse Count Value (0 to 15. Factory Default = 2).
3) Program the Pulse Time (0 to 255 Seconds. Factory Default = 60) .
4) If an Alarm on any Pulse Count Zone is to increment the Count on all Pulse Count Zones;
Enable Option 4 - "Pulse Count Handover" in "General Options 3".

SIREN OUTPUT TO OPERATE AS AN AUXILIARY

1) If the Siren (SPK) Output (Auxiliary 0) is required to operate as a normal Open Collector Auxiliary Output;
Enable Option 6 - "Siren Output operates as Auxiliary" in "General Options 3".
NOTE: IF ENABLED, A SIREN SPEAKER MUST NOT BE CONNECTED.
2) Program operation as a normal Auxiliary Output.
a) Select the Auxiliary Event Type. See Section 10 -"Tables" page 69 and 70 for details of Auxiliary Event Types.
b) Program the Auxiliary Timer if required.
c) Select the "Auxiliary Action". See Section 10 -"Tables" page 71 for details of Auxiliary Actions.

SIX DIGIT PIN CODES

1) If all PIN Codes in the system are required to be 6 digits in length;
Enable Option 1 - "6 Digit PIN Codes" in "General Options 3".
2) Program the User PIN Codes to be 6 digits in length.
CONCEPT IQ. PLUS Programmer's Manual.
NEXT 651 (Zone 1) to 666 (Zone 16)
NEXT 901
NEXT 902
NEXT 892
NEXT 892
NEXT 800 (Aux 0)
NEXT 830 (Aux 0)
NEXT 860 (Aux 0)
NEXT 892
NEXT 403 to 447
