Contact Id Event Codes - Inner Range CONCEPT IQ. PLUS Programmer's Manual

p80 Ver. 3.003 (24/4/03)
CONTACT ID EVENT CODE'S
Each event in Contact ID is sent as a string of 16 DTMF digits. For example, an alarm followed by a restore and then an opening would be 3 events. All Contact ID strings follow the format:
CCCC 18 SXYZ GG PPP K where:
CCCC 4 digit client code that identifies the panel or site.
18 Always the digits "18".
SXYZ Event code.
S = Status. 1 - Alarm or Opening. 3 - Restore or Closing. (Note: Alarm Restores only reported on Area Opening)
GG Group Byte which signifies the Area being Opened/Closed or the Area in which the alarm occurred.
PPP Point ID. This refers to either the Point number or the User ID depending on the type of event.
K Checksum.
Some receivers display a "U" (User) or a "C" (Alarm Point) in front of the PPP, depending on which of these PPP represents.
TYPE OF ALARM MESSAGE
Zone Type (Zone Inputs)
0 - Instant (Burglary)
1 - Delayed (Entry/Exit)
2 - Handover
3 - 24hr Burglary
4 - 24hr Fire
5 - 24hr Panic
6 - 24hr Duress
Tamper
Isolate
System Inputs
AC Fail (Mains power trouble)
Low Battery
Cabinet Tamper (Expander Mod. Tamper)
Siren Monitor Alarm
LAN Fuse fail
Battery Fuse fail
Comms Fail
System Reset
EVENT GROUP BYTE POINT ID
CODE (AREA)
XYZ GG
130 01 to 04 001 to 016
130 01 to 04 001 to 016
130 01 to 04 001 to 016
130 01 to 04 001 to 016
110 01 to 04 001 to 016
120 01 to 04 001 to 016
121 01 to 04 001 to 016
144 01 to 04 001 to 016
570 01 to 04 001 to 016
^ = Restore not reported.
301 00 101
302 00 102
145 00 103
320 00 104
140 00 105
140 00 106
354 00 107 ^
305 00 108 ^
TYPE OF ALARM MESSAGE
PPP
Keypad Lockout
Zone Self Test Fail
Keypad Medical Alarm (Personal Emerg.)
Keypad Panic Alarm
Keypad Duress Alarm
Keypad Fire Alarm
Spare
Spare
Spare
Spare
Spare
Test Report (Periodic)
System Input Isolate
Open / Close
By User PIN code - Single Area
By User PIN code - General Open/Close
By System* - Single Area
By System* - General Open/Close
Quick Arm
CONCEPT IQ. PLUS Programmer's Manual.
XYZ = Type of Event.
EVENT GROUP BYTE
CODE (AREA)
140 00 109 ^
307 00 110 ^
100 00 111 ^
120 00 112 ^
121 00 113 ^
110 00 114 ^
- 00 115 ^
- 00 116 ^
- 00 117 ^
- 00 118 ^
- 00 119 ^
602 00 120 ^
570 00 101 to 120
401 01 to 04 001 to 047
402 00 001 to 047
403 01 to 04 48
402 00 48
408 01 to 04 48
POINT ID
