CONCEPT IQ. PLUS Programmer's Manual.

AUXILIARY TO FOLLOW A TIMEZONE

Program a TimeZone.
1) Choose a TimeZone to Program.
2) Program a "Start Time". This is the time that the Auxiliary will be activated.
Program the Start Hour.
Program the Start Minute.
3) Program an "End Time". This is the time that the Auxiliary will be reset.
Program the End Hour.
Program the End Minute.
4) Assign the Days-of-the-Week when the TimeZone will operate.
1 - Sun. 2 - Mon.
Program any Holidays required to Qualify the TimeZone
Any Days when Auxiliary Control is not to occur, when the TimeZone would normally be Valid, must be programmed as Holidays.
Program the Holiday Month (0 - 12) and the Holiday Date (0 - 31) for up to 10 Holidays.
Program the Auxiliary Output.
1) Choose the Auxiliary to control and select the Event Type.
71 - Follow TZ1.
2) Program an Auxiliary Timer value for the selected Auxiliary if required.
(If any of the Auxiliary Actions from 2 to 13 are to be assigned)
3) Assign the "Auxiliary Action" for the selected Auxiliary.
0 - Follow Event Status.
2 - One-shot timed in Seconds.
Full details of all Auxiliary Actions are provided in Section 10 -"Tables" on page 71.

BATTERY TESTING

1) If Automatic Battery Testing is required, Enable Option 2 in "General Options 3".
2) If Battery Testing on Area Arming is required, Enable Option 3 in "General Options 3".
CALLBACK FOR REMOTE CONNECT
1) Program the Callback Telephone Number.
2) Select Option 2 - "Remote Connect with Callback" in the Remote Connect Options.
3 - Tues. 4 - Wed 5 - Thurs
72 - Follow TZ2. 73 - Follow TZ3.
1 - Invert Event Status.
3 - One-shot timed in Minutes. etc.
6 - Fri. 7 - Sat. 8 - Hol.
74 - Follow TZ4.
NEXT 750 (TZ1), 755 (TZ2), 760 (TZ3), 765 (TZ4)
NEXT 751 (TZ1), 756 (TZ2), 761 (TZ3), 766 (TZ4)
NEXT 752 (TZ1), 757 (TZ2), 762 (TZ3), 767 (TZ4)
NEXT 753 (TZ1), 758 (TZ2), 763 (TZ3), 768 (TZ4)
NEXT 754 (TZ1), 759 (TZ2), 764 (TZ3), 769 (TZ4)
NEXT 801 (Aux 1), to 810 (Aux 10)
NEXT 831 (Aux 1), to 840 (Aux 10)
NEXT 861 (Aux 1), to 870 (Aux 10)
NEXT 892
NEXT 892
NEXT 504
NEXT 512
Ver. 3.003 p37
