Inner Range CONCEPT IQ. PLUS Programmer's Manual page 77

CONCEPT IQ. PLUS Programmer's Manual.
No. Auxiliary Event Type:
125 n/a
-
130 n/a
131 Door Forced or DOTL Alarm on Door 1
132 Door Forced or DOTL Alarm on Door 2
133 Door Forced or DOTL Alarm on Door 3
134 Door Forced or DOTL Alarm on Door 4
135 n/a
-
140 n/a
141
DOTL Alarm on Door 1
142
DOTL Alarm on Door 2
143
DOTL Alarm on Door 3
144
DOTL Alarm on Door 4
NOTE: Auxiliary Event Type numbers have been structured in a logical manner to cater for expansion while providing a common Event numbering system across all
Concept IQ Versions.
Event On (Valid) when:
When this event type is set the Auxiliary operation options and Auxiliary Timer registers
are always ignored. On a Door Forced Alarm for Doors the output follows the Door
Forced alarm and will remain active until this alarm is cleared by a PIN # then OFF
command at the associated terminal. When a Door Open too Long event is initiated on
Door One the output pulses on for 500mS every five seconds, the DOTL output will reset
when the system detects door closure. This event type is used to fire DC buzzers placed
in close proximity to access doors.
When this event type is set the Auxiliary operation options and Auxiliary Timer registers
are always ignored. When a Door Open too Long event is initiated for Doors, the output
pulses on for 500mS every five seconds. This output will reset when the system detects
door closure. This event type is used to fire DC buzzers placed in close proximity to
access doors.
Event Off (Invalid) when:
Ver. 3.003 p77
