4.8 DEFAULTING THE SYSTEM.

There are four pre-defined settings available to the installer:
a) The Factory Default, and
b) Three "8 Zone / Single Area" Installer presets:
1-No Dialer 2-Contact ID Dialer
CAUTION: Defaulting the system overwrites all configuration values currently
programmed in memory.
Full details of all default options are provided in the Factory Default and Installer Presets in
the Tables section. The factory default settings are also shown throughout the
programming reference section of this manual.
THE INSTALLER PRESETS
1. No Dialler. Provides the common Installer Preset features described below.
2. Contact ID Dialer. In addition to the common features, provides:
Reporting Format Contact ID, Alarms, Restores, Isolates are reported via dialler and
Opening Report sent only after alarm, Maximum of 10 dial attempts to central station or
domestic dialling, 7 days between automatic test reports, a test report will be sent at
1:20AM. This option also requires the programming of a primary and secondary phone
number and client account code .
3. Domestic Dialler. In addition to the common features, provides: Reporting Format
Domestic Dialler ID, Alarms only are reported via dialler, Maximum of 1 dial attempt only to
domestic dialling. This option requires programming of a primary phone number.
The three "8 Zone / Single Area" Installer presets share the following common features:
• Remote connect is enabled.
• 9 rings before the system will answer an incoming call.
• Upload / download is enabled for Port 0 at 9600 Baud.
• All Area Client Codes set to 9999.
• Area 1 Entry delay Time is 30 secs and Exit delay is 60 secs.
• Holiday 1 is 1st Jan; Holiday 2 is 25th Dec; Holiday 3 is 26th Dec.
• End of Line Resistor Value is Type 3-3K3 single EOL.
• Zone 1 is Type 1-Entry/Exit Delayed; Zone 2 is Type 2-Handover.
• Zones 3 to 8 are Type 0-Instant Zones.
• Zones 1 to 8 are set for siren lockout.
• Zones 1 to 8 are in Area 1.
3-Domestic Dialer.
• Time Zone 1 is 0900 to 1700, Monday to Friday.
• Time Zone 2 is 0900 to 1300, Saturday and Sunday.
• Time Zone 3 is 0700 to 2000, Sunday to Saturday; ignore holidays.
• Time Zone 4 is 2000 to 0700, Sunday to Saturday; ignore holidays.
• Aux 0 is Siren Speaker output.
• Aux 1 set as a strobe output; Aux 2 is set as 12v output to follow the Siren.
• General Options 1 enables "Clock sync with Mains", "Zone Alarm Ind after Disarm",
"Display zone activity on terminals when disarmed", "Special Siren tone for System
Alarms" and "Single Exit beep in Home mode".
• General Options 2 enables "Terminal beeper for Day Alarms" and "Bell Squawk for
Remote Key operations".
• General Options 3 will allow "Automatic Battery Testing" and "Pulse Count Handover".
• Siren will be triggered for Cabinet Tamper.
• Dialler will be enabled for AC fail, Low Batt, Cabinet Tamper, System Reset, Siren
Monitor & Pwr /Batt Fuse.
• Panic, Fire and Medical alarms will activate the Siren and the Dialer.
• Home zone entry time is 90 secs.
• Pulse Count is set to 2 pulse counts for any zone with pulse count.
• Pulse count period is set to 60 secs.
• Siren time is 5 minutes (909), AC delay time is 0 minutes (906).
• Incorrect PIN tries will lockout the keypad for 5 mins (905).
• There will be a 255 seconds warning before an Area auto arms (907).
• If no activity on a zone and auto arm is programmed, Area will re-arm in 30 mins.
• 24 Hour Fire Zone or Smoke Detector Ignore Time is 60 secs.
• Time period allowed for walk test is 30 mins.
DEFAULTING PROCEDURE
The "Default Options" function (Address 098) is used to select one of the Installer presets;
"1-No Dialler", "2-Contact ID Dialer" or "3-Domestic Dialler".
NOTE: The "Factory Defaults" (Option 0) can also be selected.
1) Enter the Installer PIN code;
2) Select the Address for Defaulting the System. Press
3) Select the default option required. Press
Zone Lamp 1 should be now be ON with Zone Lamp 2 flashing. Then press
Ver. 3.003 p13
... .
, , ,
or or or
.
