4.6 "VALUE" DATA.

The range of Data values that can be stored in a Value Data Address depends on the
parameter being programmed. The data can be either a single digit or a multiple-digit
number.
e.g. Auxiliary Event Types: 0 to 57.
Primary Telephone No: 16 decimal digits.
DISPLAYING "VALUE" DATA.
Single Digits.
These are numbers between 0 and 16 and are displayed by the Zone Lamps "1" to
"16" and the "0" Lamp on the LED Terminal.
Multi digit / Sequential numbers.
(Data values from 17 to 255, and strings of numbers such as PINs & Phone nos.)
These numbers are displayed one digit at a time sequentially via the Zone Lamps
and the "0" Lamp. A chirp will sound each time the display steps to the next digit.
When the end of the value is reached, 3 short beeps will sound to indicate there are
no more digits to display.
Example. If the existing value at the Address is 120.
When the Address is entered, The "1" Lamp will flash. The flashing Lamp indicates
•
that this value is a multi-digit number.
• After 2 seconds the "2" Lamp will flash and a chirp will sound.
• After 1 second the "0" Lamp will flash and 3 short beeps will sound.
The "1" lamp will now flash slowly to prompt for the 1st digit of the new data.
•
PROGRAMMING MULTI-DIGIT NUMBERS.
When programming any Multi-digit number, only one Address is selected regardless of the
number of digits to be entered.
Example. To program the data "9 8 7 6 5 4 3 2" as the Primary Telephone Number.
1) Enter Installer PIN code;
2) Press , then the Address for the Primary Telephone Number
Any existing data will now be displayed as described above.
3) Enter the new Data string
4) Select the next Address to program, or Exit Programming Mode.
Area Entry Delay (Seconds): 0 to 255.
... .
, then
4.7 "OPTION" DATA.
Option data is used to allow the Installer to select between two alternatives (Select/De-
select, Enable/Disable, Assign/Un-assign, etc.) for up to 8 Options or Items that relate to a
particular feature.
DISPLAYING "OPTION" DATA.
Option Data is displayed on the Zone 1 to 8 Lamps on the LED Terminal.
When a Zone Lamp is ON, the option is Selected. (Enabled or Assigned)
When a Zone Lamp is OFF, the option is De-selected. (Disabled or Un-assigned)
EDITING OPTION DATA.
Option Data is programmed by first selecting the Address of the Data to be edited in the
normal manner.
Any number of specific options are then Selected or De-selected by the following method:
1) Check the current setting of the option on the Zone Lamps.
2) For each option that needs to be changed, Press the option number
This procedure toggles the setting of the selected option.
i.e. If the option was De-selected, it will be Selected. If the option was already
Selected, it will be De-selected.
3) When all required changes have been made, press
To Select ALL available options:
To De-select ALL available options: Press
Example. To Enable "Alarms" (Option 1), "Restores" (Option 2) and "Open Report only
after alarm" (Option 4) in "Dialer Options" (Address 506).
1) Enter Installer PIN code;
2) Select the Address for Dialer Options. Press
The existing data will now be displayed as described above.
3) Enable the 3 options required. (Assuming none of the options already enabled)
.
Press ,
IMPORTANT NOTE: Remember that the same key sequence is used to Disable an
option that is already Enabled.
CONCEPT IQ. PLUS Programmer's Manual.
Press , then
, then .
... .
,
, , (Zone Lamps 1, 2 and 4 should now be ON) then
(1 to 8).
.
.
, , .
.
