Inner Range CONCEPT IQ. PLUS Programmer's Manual page 57

CONCEPT IQ. PLUS Programmer's Manual.
ADDRESS DEFAULT
(Data Type)
601-616 (Value Data)
Zone 1
1 - Delayed
Zone 2
2 - Handover
Zone 3 to 16
0 - Instant
FUNCTION
Single EOL: 0 -1k
6 -5k6
Dual EOL: 11 -2k2, 2k2
(Provides Tamper state. 1st Value is Series Resistor, 2nd Value is Resistor across contacts)
Zone Doubed: 15 -1k, 3k3, 6k8.
ZONE TYPE
Programming Addresses for Zone Type programming:
Zone 1 2
Address 601 602
Zone Type Details:
0 Instant(Factory Default for Zones 3 to 16). When an "Instant" Zone goes into alarm, the system immediately generates an alarm. The
Zone processing will not be delayed by Entry or Exit Timers. Processing is the same whether Armed in Normal Mode or Home Mode.
1 Delayed A "Delayed" Zone will have Entry/Exit delay periods applied, as programmed in the "Entry delay" and "Exit delay" Addresses
for the Area that the Zone is assigned to. (General Area/Area 1 in a Single Area system)
If more than 1 Area assigned and 2 or more of those Areas Armed or Disarmed at the same time, the longest Entry/Exit Delay will apply.
Processing is the same whether Armed in Normal Mode or Home Mode.
2 Hand-over When a "Handover" Zone goes into alarm, the alarm will be processed under these two conditions:
If a Delayed Zone has already been triggered in the same Area, the system will ignore the alarm for the duration of the Entry or Exit timer.
i.e. The Zone will be processed as a delayed Zone.
If a Delayed Zone has not been triggered, the system will process the Zone as an "Instant" Zone.
Processing is the same whether Armed in Normal Mode or Home Mode.
3 Away Instant / Home Isolate.
4 Away Instant / Home Delayed.
Delayed by the "Homeguard Time" (Address 900) when Armed in Home Mode.
5 Away Delayed / Home Isolate.
Isolated when Armed in Home Mode.
6 Away Delayed / Home Delayed.
Delayed by the "Homeguard Time" (Address 900) when Armed in Home Mode.
1 -1k5 2 -2k2 3 -3k3
7 -6k8 8 -10k 9 -12k
12 -2k2, 6k8
16 -1k, 3k3, 6k8. No separate tamper state.
3 4 5 6 7
603 604 605 606 607
Same as Type 0 - "Instant" when Armed in Away (Normal) Mode. Isolated when Armed in Home Mode.
Same as Type 0 - "Instant" when Armed in Away (Normal) Mode.
Same as Type 1 - "Delayed" when Armed in Away (Normal) Mode.
Same as Type 1 - "Delayed" when Armed in Away (Normal) Mode.
4 -3k9 5 -4k7
10 -22k
13 -3k3, 6k8
See installation manual for details.
8 9 10 11 12
608 609 610 611 612
Ver. 3.003 p57
14-10k, 10k
13 14 15 16
613 614 615 616
