p10 Ver. 3.604 (31/03/05)

2.6 WIRELESS REMOTE AND THE IQ .

The IQ provides keyless functionality (Wireless Remote) via an RF keyfob (Transmitter) and an RF LAN Module or RF Terminal.
The Keyfob is registered in the RF module or RF Terminal and when a User is assigned to the Keyfob the IQ panel uses the registered information to match the Keyfob and User.
Up to 6 Keyfobs can be programmed for each RF Module or RF Terminal (maximum of 24 Keyfobs) providing;
Arm and Disarm in the User's Area List, Turn Auxiliary 2 on the Control Module ON and OFF and activate Panic by pressing 2 keys simultaneously.
3.1 INTRODUCTION.

THE PROGRAMMING KEY.

The IQ Programming Key is a portable non-volatile memory device housed in a convenient
"key tag".
The Programming Key allows system programming to be uploaded from the Control
Module or downloaded to the Control Module by simply inserting the Programming Key
into Serial Port 0 and performing a simple key sequence on the LED Terminal. See below.
A built-in Lamp (embedded in the plastic surface) on the Programming Key visually
indicates when data transmission is active.
IQ PROGRAMMING KEY & FLASH INTERFACE.
This device allows the Programming Key to be connected to a PC for transferring Panel
data to and from the Upload/Download software.
NOTE: The IQ Programming Key & Flash Interface can also be used to connect a PC to
the "Flash" connector (JP8) on the Controller for the purpose of providing a Flash Upgrade
of the Controller Firmware version.
Refer to your Inner Range IQ distributor for more details.
3.2 IMPORT DATA FROM THE PROGRAMMING KEY.
This Mode allows the Installer to copy the programming contents of the Programming Key
into the Control Module.
3. PROGRAMMING KEY
IMPORTANT NOTE: The new data will override the existing contents of the Control
Module memory.
Connect the Programming Key to Serial Port 0 on the Control Module.
Select the Import Data Mode:
Enter PIN;
The Lamp on the Programming Key will flash slowly to indicate data is being copied.
The Terminal beeper will sound 3 short beeps if the operation was successful, or 1 long
beep if unsuccessful.
3.3 EXPORT DATA TO THE PROGRAMMING KEY.
This Mode allows the Installer to copy the programming contents of the Control Module into
the Programming Key.
IMPORTANT NOTE: The Control Module data will override the existing contents of the
Programming Key.
Connect the Programming Key to Serial Port 0 on the Control Module.
Select the Export Data Mode:
Enter PIN;
The Lamp on the Programming Key will flash quickly to indicate data is being copied.
The Terminal beeper will sound 3 short beeps if the operation was successful, or 1 long
beep if unsuccessful.
INNER RANGE IQ. PLUS Programmer's Manual.
... , then , then the Mode number;
... , then , then the Mode number;
, , .
, , .
