CONCEPT IQ. PLUS Programmer's Manual.
ADDRESS DEFAULT
(Data Type)
811-829
Spare
830-840
(Value Data)
841-859 Spare
860-870
(Value Data)
0 - Follow Event
Status
FUNCTION
A wide range of Auxiliary Event Types are available. Full details are found in the Tables section on page 71-73.
IMPORTANT NOTE: Auxiliary Event Types; 7 -Smoke Detector Reset, 13 & 14 -User Auxiliary A & B, 15 -Day Alarm, 17 -RF Auxiliary and
21 to 36 -Zone 1 to 16 in Alarm can only be turned off by an Auxiliary Timer or from the Auxiliary Control and Test Menu. (NEXT 24).
It is therefore recommended that these Event Types should also have an Auxiliary Action assigned that incorporates a timer (i.e. Auxiliary
Actions 2 to 13) and a suitable Auxiliary Timer value programmed.
Common Auxiliary Event Types:
1 Burglary Alarm. (Strobe)
2 Fire Alarm.
131 Door Forced or DOTL Alarm on Door One
AUXILIARY TIMER VALUE
These Addresses allow a Timer Value to be programmed for any Auxiliary Actions that incorporate a Timer.
(Auxiliary Actions 2 to 13)
The Timer Value will be in Seconds or Minutes depending on which is specified in the Auxiliary Action. (If a timer value of 1 to 4 Minutes is
required, program the timer in Seconds)
Programming Addresses for Auxiliary Timer programming:
Auxiliary 0 1
Address 830 831
AUXILIARY ACTION
15 Auxiliary Actions are available. Full details of all Auxiliary Actions are found in the Tables section on page 74.
Common Auxiliary Actions:
0 Follow Event Status.
1 Invert Event Status.
Programming Addresses for Auxiliary Action programming:
Auxiliary 0 1
Address 860 861
3 Zone Bypass on Arming.
4 System Alarm.
2 3 4 5 6
832 833 834 835 836
2 One Shot Timed in Seconds.
4 One Shot Timed in Minutes.
2 3 4 5 6
862 863 864 865 866
9 Follow Ext. Siren 11 EntryTimer (Any Area)
10 Follow Int. Siren 12 Exit Timer (Any Area)
141 DOTL Alarm on Door One
7 8 9 10
837 838 839 840
7 8 9 10
867 868 869 870
Ver. 3.003 p63
