AUXILIARY EVENT TYPES

No. Auxiliary Event Type:
0 User (Master) Control/Test only
1 Burglary Alarm (Strobe)
2
Fire Alarm
3 Zone Bypass on Arming
4 System Alarm
5 System Armed
6 System Disarmed
7 Smoke Detector Reset
8 Comms Fail
9
External Siren
10 Internal Siren
11 Entry Timer (Any Area)
12
Exit Timer (Any Area)
13 User Auxiliary A.
14 User Auxiliary B.
15
Day Alarm.
16 Bell Squawk
17 RF Auxiliary
21
Zone 1 in Alarm
22 Zone 2 in Alarm
23
Zone 3 in Alarm
24 Zone 4 in Alarm
25 Zone 5 in Alarm
26 Zone 6 in Alarm
27 Zone 7 in Alarm
This table is continued on the following page.
NOTE: Auxiliary Event Type numbers have been structured in a logical manner to cater for expansion while providing a common Event numbering system across all
Concept IQ Versions.
Event On (Valid) when:
Turned On via NEXT 24 "Auxiliary Control & Test" Mode.
Any Burglary alarm. (Alarm on Zone Types 0, 1, 2 or 3)
Any Fire alarm . (Alarm on Zone Type 4)
Any Zone Automatically or Manually Bypassed (Isolated) on arming an Area.
Any System Input in alarm.
System fully Armed. Single Area system -Area 1 Armed.
Multi Area system -All Areas in the General Open/Close Area List Armed. (Address
607)
System fully Disarmed. Single Area system -Area 1 Disarmed.
Multi Area system -All Areas in the General Open/Close Area List Disarmed. (Address
607)
PIN code, <OFF> is entered at a Terminal after a Fire Zone has been activated.
System failed to report. Follows Comms Fail System Input.
External Siren (SPK Output) active.
Siren Timer or Siren Hold-off Timer Started.
Any Area Entry timer on.
Any Area Exit timer on.
PIN Code entered by User Type 4.
PIN Code entered by User Type 5.
Any "Day alarm" Zone Type Unsealed when Area not Armed.
RF Wireless remote action activates Bell Squawk on Siren.
Arm (Button 1) - 1 Squawk.
Disarm (Button 2) - 2 Squawks.
Home Arm (Button 3) / Aux Control (Button 4) - NO Squawks.
Error (Area already Armed) - 5 Squawks.
RF Wireless remote Button 4
Zone in Alarm.
(When Area is Armed)
Event Off (Invalid) when:
Turned Off via NEXT 24 "Auxiliary Control & Test" Mode.
The Area that the Alarm occured in, is Disarmed (Turned Off).
System Dis-armed (Any Area is disarmed) or PIN <OFF> entered.
Any Area turned off or All Zones De-Isolated.
No System Input remaining in alarm.
Single Area system -Area 1 Armed.
Multi-Area system -Any Area in the General Open/Close Area List
Disarmed.
Single Area system -Area 1 Disarmed.
Multi-Area system -Any Area in the General Open/Close Area List Armed.
Must be programmed to turn Off by an Auxiliary Timer.
On the next successful dialer communication.
Siren off.
Siren off.
Entry timer off.
Exit timer off.
Should be programmed to turn Off by Auxiliary Timer.
Should be programmed to turn Off by Auxiliary Timer.
Must be programmed to turn Off by an Auxiliary Timer.
Follows Event
Must be programmed to turn Off by Auxiliary Timer.
Must be programmed to turn Off by Auxiliary Timer.
Ver. 3.003 p75
