Walk Testing; Wireless Remote Control; Zone Self Testing - Inner Range CONCEPT IQ. PLUS Programmer's Manual

p42 Ver. 3.003 (24/4/03)

WALK TESTING

1) Program the "Walk Test Time" (0 to 255 Minutes. Factory Default = 30 Minutes)
(Maximum period that the system can remain in Walk Test Mode)
2) Program/Check the Users who require access to Walk Test Mode.
Program a PIN Code, Assign the Area/s required, and set the User Type to Type 7 - "Master".

WIRELESS REMOTE CONTROL

1) Ensure that an RF Terminal or RF Module is connected to the LAN and commissioned as described in the installation instructions of these products.
2) If a "Bell Squawk" on the Siren (or another Auxiliary Output), and/or Flashing on the Strobe is required to indicate successful Wireless operations:
Enable Option 3 - "Bell Squawk on Siren for Wireless operations" in General Options 2.
Enable Option 7 - "
Flash on Strobe for Wireless Remote Key operations
3) If an Auxiliary Output is required to provide the "Bell Squawk" indications.
a) Choose the Auxiliary to control and select Event Type 16 - "Bell Squawk".
b) Check that the "Auxiliary Action" for the selected Auxiliary is set to Type 0 - "Follow Event Status".
4) If an Auxiliary Output is required to be controlled by Button 4 on the Wireless Remote Key:
a) Choose the Auxiliary to control and select Event Type 17 - "RF Auxiliary".
b) Program an Auxiliary Timer value for the selected Auxiliary.
c) Assign the required "Auxiliary Action" for the selected Auxiliary.
2 - One-shot timed in Seconds.

ZONE SELF TESTING

1) Enable Self Test operation for any Zone Inputs that are to be automatically tested by the system.
Enable Option 5 - "Self Test Zone" in the Zone Options.
2) Program the Zone Self Test Period. (0 to 15. Factory Default = 0)
0 = Zone Self Test Disabled.
3) Enable Zone Self Test Fail Reporting via Dialler if required.
Enable Option 8 - "Zone Self-Test Fail".
3 - One-shot timed in Minutes.
1 to 15 = Number of Arming periods to be included in Zone Self Test processing.
" in General Options 3.
Types 4 to 13 may also be suitable.
CONCEPT IQ. PLUS Programmer's Manual.
NEXT 912
NEXT 403 to 447
NEXT 891
NEXT 892
NEXT 801 (Aux 1), to 810 (Aux 10)
NEXT 861 (Aux 1), to 870 (Aux 10)
NEXT 801 (Aux 1), to 810 (Aux 10)
NEXT 831 (Aux 1), to 840 (Aux 10)
NEXT 861 (Aux 1), to 870 (Aux 10)
NEXT 651 (Zone 1) to 666 (Zone 16)
NEXT 903
NEXT 898
