Inner Range CONCEPT IQ. PLUS Programmer's Manual page 54

p54 Ver. 3.003 (24/4/03)
ADDRESS DEFAULT
(Data Type)
564 0 - Multi-Area
565-568 Spare
569 (Option Data)
1 - No
2 - No
3 - No
4 - No
570-589 (Value Data)
570-571 1 (January ) / 1
572-573 12 (December ) / 25
574-575 12 (December ) / 26
576-577
578-579
580-581
582-583
584-585
586-587
FUNCTION
TERMINAL 4 ASSOCIATED AREA(0 - 4)
MULTI AREA OPTIONS
When the system operates in Multi-Area mode, it can be configured as four separate Areas, or as 3 Areas with Area 4 as the Sub-Area.
Sub-Area Mode. When this mode is selected, Area 4 will only be armed when all the Areas included in Area 4's "Sub-Area list" are armed.
Area 4 can still be Disarmed from a Terminal or Keyswitch, but will not Arm unless all the Areas in the Sub-Area List are Armed.
NOTE: The Area 4 Exit Time and Entry/Exit Auxiliary will not operate in this mode. Only the Exit time and Entry/Exit Auxiliary of the control-
ling Area/s are used.
1 - Enable Area 4 as the Sub-Area. When this option is selected, Area 4 will always Arm in Away Mode when Armed as a Sub-Area.
2 - Include Area 1 in Area 4 Sub-Area List
3 - Include Area 2 in Area 4 Sub-Area List
4 - Include Area 3 in Area 4 Sub-Area List
HOLIDAYS
Each Holiday has 2 Address locations for defining the Holiday Month and the Day of the month. Any TimeZone that is not set to be Valid on
Holidays will be Invalid on any date defined as a Holiday.
HOLIDAY MONTH (0 - 12)
HOLIDAY DAY (0 - 31)
HOLIDAY 1 PROGRAMMING.
HOLIDAY 2 PROGRAMMING.
HOLIDAY 3 PROGRAMMING.
HOLIDAY 4 PROGRAMMING.
HOLIDAY 5 PROGRAMMING.
HOLIDAY 6 PROGRAMMING.
HOLIDAY 7 PROGRAMMING.
HOLIDAY 8 PROGRAMMING.
HOLIDAY 9 PROGRAMMING.
This Address sets the Month component of the Date for the Holiday.
A value of 0 means no Date is defined.
This Address sets the Day component of the Date for the Holiday.
A value of 0 means no Date is defined.
NOTE:
Holidays will only take effect when the system clock passes
through midnight into, and out of, the day that is designated as a
Holiday.
If midnight is skipped by adjusting the system clock (via NEXT 33
- View/Set the Time and Date, or Upload/Download), the Holiday
will not be recognised.
