Programming Of Advanced Features - Inner Range CONCEPT IQ. PLUS Programmer's Manual

p34 Ver. 3.003 (24/4/03)
The following features can be programmed to operate in addition to the Primary system features already described in the Basic Programming Guide.
The programming procedures in this section assume that the system has already been programmed according to the procedures in Section 7 -"Basic Programming Guide".
Page Feature
35 Access Control
36 Auto-Arm / Auto Disarm.
37 Auxiliary to Follow a TimeZone
37 Battery Testing.
38 Callback for Remote Connect.
38 Call Forwarding.
38 Computer connection (Local)
38 Computer Connection (Local) Printer
39 Day Alarm.
39 Defer Arming
39 DTMF Remote Control
39 Keyswitch Arming and Disarming.
40 Pulse Counting.
40 Siren output to operate as an Auxiliary.
40 Six Digit PIN Codes.
41 Smoke Detector Reset
41 Sub Areas.
41 User Auxiliaries
42 Walk Testing.
42 Wireless Remote Control.
42 Zone Self Testing.

8. PROGRAMMING OF ADVANCED FEATURES.

Description
Access Review to be written to General Review, Siren output when Door Forced alarm, Door Forced & DOTL reporting to the dialler.
TimeZones can automatically Arm and/or Disarm Areas in Away or Home mode and provide auto-arm warnings if required.
TimeZones can control Auxiliary outputs for automatic control of ancillary devices such as lighting, irrigation, pool filters, etc.
Automatic battery testing can be performed every 8 hours and/or on Area arming to ensure continuous operation if the AC power fails
Requirement for the system to callback a pre-programmed number to establish remote connection for Upload/Download.
The system can dial your call divert number when armed and the un-divert number when disarmed.
A computer can be connected directly to the Controller via the on-board Serial Port for Upload/Download.
A printer can be directly connected to the Controller via the on-board Serial Port
A Zone Input can operate an Auxiliary output for activating Door Bells, lights, etc. when disarmed.
Allows automatic arming if no movement is detected for a specified period to ensure thatat an Area is not left disarmed.
Remote Control of Areas and Auxiliaries can be provided from any touch-tone (DTMF) telephone.
Keyswitches can be used to Arm and/or Disarm the system in addition to, or in place of, PIN Codes or Wireless Remote Keys.
Provides more sophisticated monitoring of detection devices that require verification of an abnormal condition.
The Siren Speaker output can be used as a normal Auxiliary output if required.
Forces all PIN Codes programmed to be 6 digits in length for a higher level of User verification integrity.
User PIN Code operation to momentarily activate an Auxiliary output to reset latching Smoke Detectors.
Area 4 can be defined as a Sub-Area (or common Area) allowing it to be armed/disarmed by any, or all, of the other Areas.
PIN Codes can be programmed for the sole purpose of controlling one of 2 "User" Auxiliaries.
Allows Users to manually test detection devices.
Wireless Remote Keys can be assigned to the system for Area control, Auxiliary control and Panic alarm.
Zones can be tested when the Area is disarmed to check for masking or other problems.
CONCEPT IQ. PLUS Programmer's Manual.
