Inner Range CONCEPT IQ. PLUS Programmer's Manual page 49

CONCEPT IQ. PLUS Programmer's Manual.
ADDRESS DEFAULT
(Data Type)
9 Rings
513
0 - Disabled
514
(Value Data)
1 - Upload/Download
515
2 - Printer
517
FUNCTION
0 - Remote connect for Upload/Download not allowed
1 - Remote connect for Upload/Download enabled
2 - Remote connect for Upload/Download enabled with Callback.
If Option 1 or 2 is selected, "Number of Rings" must be programmed in Address 513.
If Option 2 selected, "Callback Telephone number" must be programmed in Address 504.
RINGS TO ANSWER (3 - 16)
This Address sets the number of rings before the system will answer an incoming call. Do not program a value of less than 3 rings.
This setting is relevant to both Upload/Download connection and DTMF remote control connection.
ANSWER MACHINE (FAX) BYPASS
This feature is used when Upload/Download software or DTMF Telephone is trying to remotely connect to the system, and an Answering
Machine is connected to the same Telephone line. If this feature is enabled, the remote device must call the system, then hang up within
three rings. If the remote device calls the system again within the programmed "Follow-on" time then the system will answer the call on the
first ring & connect.
0 - Answering Machine Bypass disabled
1 - Follow-on time = 10 secs
SERIAL PORT OPTIONS
Serial Port options allow the Installer to program the Communications Task and Baud rate for the Serial Port on the Control Module. These
Ports can then be used for Direct connection of a PC for Upload/Download using the "Port 0 Interface Cable", or to a Printer, printing an
alarm summary in real time.
PORT 0 : COMMS TASK
PORT 1 : COMMS TASK
NOTE: While Upload/Download software is connected and communicating with the Control Module, DTMF Remote Control is temporarily
disabled.
0 - Serial Port not used
2 - Printer
2 - Follow-on time = 30 secs
3 - Follow-on time = 60 secs
1 - Upload/Download
3 - Spare
Ver. 3.003 p49
