AUXILIARY ACTIONS

Type ACTION
0 Follow Event Status
1 Invert Event Status
2 One Shot timed in Seconds
3 One Shot timed in Minutes
4 One Shot on Invalid timed in Seconds
5 One Shot on Invalid timed in Minutes
6 One Shot with Reset timed in Seconds
7 One Shot with Reset timed in Minutes
8 One Shot on Invalid with Reset timed in Seconds
9 One Shot on Invalid with Reset timed in Minutes
10 One Shot with Retrigger timed in Seconds
11 One Shot with Retrigger timed in Minutes
12 One Shot on Invalid with Retrigger timed in Seconds
13 One Shot on Invalid with Retrigger timed in Minutes
14 Toggle on Valid
15 Toggle on Invalid
DESCRIPTION
On when Event goes Valid / Off when Event goes Invalid.
Off when Event goes Valid / On when Event goes Invalid.
On when Event goes Valid for a time period specified in Seconds.
When this Action is triggered, it will always time for the full Timer Value specified.
On when Event goes Valid for a time period specified in Minutes.
When this Action is triggered, it will always time for the full Timer Value specified.
On when Event goes Invalid for a time period specified in Seconds.
When this Action is triggered, it will always time for the full Timer Value specified.
On when Event goes Invalid for a time period specified in Minutes.
When this Action is triggered, it will always time for the full Timer Value specified.
On when Event goes Valid for a time period specified in Seconds.
Off when timer expires or when Event goes Invalid.
On when Event goes Valid for a time period specified in Minutes.
Off when timer expires or when Event goes Invalid.
On when Event goes Invalid for a time period specified in Seconds.
Off when timer expires or when Event goes Valid.
On when Event goes Invalid for a time period specified in Minutes.
Off when timer expires or when Event goes Valid.
On when Event goes Valid for a time period specified in Seconds; Subsequent "Valids" will restart the timer if still running.
On when Event goes Valid for a time period specified in Minutes; Subsequent "Valids" will restart the timer if still running.
On when Event goes Invalid for a time period specified in Seconds; Subsequent "Invalids" will restart the timer if still running.
On when Event goes Invalid for a time period specified in Minutes; Subsequent "Invalids" will restart the timer if still running.
Toggles state when Event goes Valid.
Toggles state when Event goes Invalid.
