p56 Ver. 3.003 (24/4/03)
ADDRESS
DEFAULT
(Data Type)
596-599
Spare
600
3 -3k3 Single EOL
(Value Data)
FUNCTION
New Zealand.
Daylight Saving Time normally starts on the first Sunday in October, and ends sometime in March.
Europe.
Daylight Saving Time normally starts on the last Sunday in March, and ends on the last Sunday in October.
e.g.
25 March 2001 to 28 October 2001
NOTE: These dates are only a guide, and should be checked with a reliable local source.
Comprehensive information on DST Start and End dates for most world locations can be found at:
Time and date.com
http://www.timeanddate.com/time/
ZONE INPUT PROGRAMMING OVERVIEW
Zone programming allows the Installer to configure how the Zone Inputs are processed. A "Zone Type" and a number of processing
options are programmed for each individual Zone, while parameters for Pulse Counting, Terminating Resistors and Zone Self Testing are
programmed as global Zone Options.
END-OF-LINE RESISTOR TYPE
This data sets the value/s of the End-Of-Line (Terminating) resistor/s used for the Zone inputs. This is a global setting for all Zone inputs
connected to the system.
*NOTE: The "Zone Doubling" option allows Zones 1 to 8 on the Control Module to support two detection devices on each Zone input.
The additional 8 devices will be recognised and processed as Zones 9 to 16. Zone Inputs on the plug-on Zone/Auxiliary Expander board
will be ignored.
The installation kit provides 1k, 3k3 and 6k8 Resistors. Typical "Terminating Resistor" settings will be:
If Single End-Of-Line is used:
If Dual End-Of-Line is used:
If Zone Doubling is used:
If the system is replacing another product, and the detectors already have Terminating Resistors of a different value, the Terminating
Resistors may be retained by choosing the setting that matches the existing values.
3
(3k3)
13
(3k3, 6k8)
15
(1k, 3k3, 6k8)
