CONCEPT IQ. PLUS Programmer's Manual.
ADDRESS
DEFAULT
(Data Type)
(Value Data)
900
90 Seconds
901
2
902
60 Seconds
903
0 Arming Periods
(Zone Self-Test
Disabled)
904
5 Minutes
FUNCTION
TIMERS AND COUNTERS
HOMEGUARD TIME (HOME ZONE ENTRY DELAY)
Sets the period of time for Entry Delay on Zones programmed to be delayed in Home Mode. e.g. Zone Types 4, 6 and 9.
This timer will apply when any of these types of Zones are activated in an Area that is Armed in Home Mode.
PULSE COUNT
(0 - 15)
For any Zone defined as a Pulse Count Zone, the Zone must go into alarm at least the number of times specified in the "Maximum Pulse
count", within the specified "Pulse time" for the alarm to be recognised.
This data sets the maximum Pulse count for any Zones defined as "Pulse count" Zones in the Zone Options.
(Addresses 651 to 666, Option 4.)
PULSE TIME (0 - 255 SECONDS)
This data sets the Pulse count period, for any Zones defined as Pulse count Zones in the Zone Options.
(Addresses 651 to666, Option 4)
ZONE SELF-TEST PERIOD(0 - 16 ARMING PERIODS)
This data sets the number of arming periods to be included in the Zone Self-Test processing.
Any Zone defined as a Self-Test Zone must go un-sealed at least once during this Self-Test period, or a Self-Test system input alarm will be
generated. The Self-Test Zone option is enabled by Option 5 in Addresses 651 (Zone 1) to 666 (Zone 16).
A setting from 0 to 16 arming periods can be defined.
SIREN TIME
(0 TO 255 MINUTES)
This Address sets the time the siren will sound when an alarm has occurred on a Zone Input.
Note that an alarm on a Zone Input will only activate the Siren when:
-
The Zone Type selected is in the range of Type 0 to Type 12. (Address 601 [Zone 1] to 616 [Zone 16])
-
The Zone Options (Address 651 [Zone 1] to 666 [Zone 16]) must have Option 1 (Silent), Disabled.
-
For Zone Types 11 (24Hr Fire) & 12 (24Hr Panic), Siren activation must also be enabled in the "Emergency Options".
(Address 899: Option 1-Panic alarm sounds Siren. Option 3-Fire alarm sounds Siren)
(0 TO 255 SECONDS)
0 = Zone Self-Test Disabled.
Ver. 3.003 p69
