CONCEPT IQ. PLUS Programmer's Manual.
SMOKE DETECTOR RESET (Resets Latching Smoke Detectors by temporarily removing power)
1) Program the Smoke Detector Reset Auxiliary.
a) Choose the Auxiliary to control and select Event Type 7 - "Smoke Detector Reset".
b) Program an Auxiliary Timer value for the selected Auxiliary.
c) Assign Auxiliary Action 2 - "One-shot timed in Seconds" for the selected Auxiliary.
2) Program the "24Hr Fire Zone Ignore Time if required. (0 to 255 Seconds. Factory Default = 60)
(Ignore timer is started by a Smoke Detector Reset Event)
SUB-AREA OPERATION
If Area 4 is required to operate as a Sub-Area (or Common Area) to other Areas in the system, program the "Multi-Area Options".
a) Enable Area 4 as the Sub-Area.
b) Assign the required Areas to the Area 4 Sub Area List.
NOTE: Area 4 will always Arm in Away mode when Armed as a Sub-Area.

USER AUXILIARIES

1) Assign the Auxiliary Event Type to the selected Auxiliary to control.
Type 13 - "User Auxiliary A"
2) Program an Auxiliary Timer value for the selected Auxiliary.
3) Assign the required "Auxiliary Action" for the selected Auxiliary.
2 - One-shot timed in Seconds.
See Section 10 -"Tables" page 71 for details of all Auxiliary Actions.
4) Program one or more User PIN Codes for "User Auxiliary" operation.
Set the User Type to Type 4 - "User Auxiliary A"
NOTE: User Auxiliary PIN Codes cannot be used to perform any other operations.
Enable Option 1.
Area 1 - Enable Option 2: Area 2 - Enable Option 3: Area 3 - Enable Option 4.
Type 14 - "User Auxiliary B"
3 - One-shot timed in Minutes.
Type 5 - "User Auxiliary B".
NEXT 861 (Aux 1), to 870 (Aux 10)
Types 4 to 13 may also be suitable.
Ver. 3.003 p41
NEXT 801 (Aux 1), to 810 (Aux 10)
NEXT 831 (Aux 1), to 840 (Aux 10)
NEXT 911
NEXT 569
NEXT 801 (Aux 1), to 810 (Aux 10)
NEXT 831 (Aux 1), to 840 (Aux 10)
NEXT 861 (Aux 1), to 870 (Aux 10)
NEXT 403 to 447
