Regulatory compliance
Safety ...................................... CE, UL
EMI/EMC ................................. CE, EN60950-1
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.

Hardware

Network Port 1: RJ45

Function:
Connector type:
Pin-out details:
Mating connector:
Recommended cable:
Maximum cable length:
Comms standard:
Ethernet (MAC) address:
IP address:
Port I is used for network connectivity and supports
10/100/1000BASE-T (Gigabit Ethernet) copper
connections.
Shielded RJ-45 Socket.
Data TX/RX
indicator
Pin Function
TX_D1+ (TX+)
1
TX_D1– (TX–)
2
RX_D2+ (RX+)
3
4 BI_D3+
Shielded RJ-45 Plug.
CAT 5E or CAT 6 Shielded twisted pair (STP).
100 meters (330 feet).
10/100/1000BASE-T (Gigabit Ethernet)
Each address is unique and in the format 0:E0:AA:10:
where:
is in the range 00 – FF,
yy
is in the range 00 – FF
xx
For example: Port I: 00:E0:AA:10:00:18
Factory-set default is:
Port I: 192.168.0.1
User-definable via the serial interface.
VN-Matrix 300 • Technical Data
Network Status
indicator
Pin Function
BI_D3–
5
RX_D2– (RX–)
6
BI_D4+
7
8 BI_D4–
:
xx yy
