User's Manual
VSC 75
Video Scan Converter
68-483-01
Printed in the USA
Advertisement
Table of Contents
Related Manuals for Extron electronics VSC 75
Summary of Contents for Extron electronics VSC 75
- Page 1 User’s Manual VSC 75 Video Scan Converter 68-483-01 Extron Electronics, Europe Extron Electronics, Asia Extron Electronics Information Extron Electronics, USA Printed in the USA Beeldschermweg 6C, 3821 AH Amersfoort 135 Joo Seng Rd. #04-01, PM Industrial Bldg. ExtronWEB : www.extron.com 1230 South Lewis Street, Anaheim, CA 92805 ™...
- Page 2 à ces opérations car l’ouverture ou le Conserver les instructions• Ranger les consignes de sécurité afin de Extron Electronics will, at its option, repair or replace said products or components, to retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.
-
Page 3: Table Of Contents
Installing the software ............3-6 Using the software ..............3-6 Appendix • Specifications Part Numbers, and Accessories ..................A-1 Specifications ................. A-2 Included Parts ................. A-4 Accessories ................A-4 68-483-01 B Printed in the USA 09 00 VSC 75 Table of Contents... -
Page 4: Chapter 1 • Introduction
Table of Contents, cont’d VSC 75 Chapter One Introduction About the VSC 75 Features VSC 75 Table of Contents... - Page 5 VSC 75’s settings via front panel controls, executive mode locks all the front panel The VSC 75 is 1U high and one half rack wide. It is rack features except centering controls. Adjustments can mountable, and has an internal, autoswitching power still be made via RS-232 control when executive supply.
-
Page 6: Chapter 2 • Installation And Operation
Introduction, cont’d VSC 75 Chapter Two Installation and Operation Installation Overview Mounting the VSC 75 Front Panel Features Rear Panel Features Cabling Optimizing the Image Troubleshooting VSC 75 Introduction... -
Page 7: Installation Overview
If feet were installed on the bottom of the VSC 75, remove them. Place the VSC 75 on one half of the 1U (one unit high, one unit wide) rack shelf (part #60-190-01). Align the front of the VSC 75 with the front of the shelf, and align the threaded holes on the bottom of the VSC 75 with the holes in the rack shelf. -
Page 8: Front Panel Features
Centering/Pan/Size • Lights green without blinking, the input signal is within range, and the VSC 75 has locked to that rotary controls (10). Observe the picture on screen as particular resolution. -
Page 9: Rear Panel Features
— Connect a VGA-type computer S-video output connector — This 4-pin mini-DIN to the VSC 75 via this 15-pin D connector (and the connector is for S-video output. provided Mac-VGA cable) to use a VGA-type computer as the video signal source. -
Page 10: Mac-Hv/Vga Cable Connector Pin Assignments
OUTPUTS VIDEO S-VIDEO • If the source computer is a VGA-type PC, plug the Mac (15-pin D) end into the VSC 75, and plug 50/60 Hz RS-232 RS-232 Control the other (15-pin HD) end into the computer’s video output connector. -
Page 11: Optimizing The Image
The size function remains active for 8 seconds after the rotary controls become inactive. The rotary controls then default to the standard centering and pan functions. VSC 75 Installation and Operation 2-10 VSC 75 Installation and Operation 2-11... -
Page 12: If The Image Is Not Displayed Correctly
If the scan converter does not respond to controls Serial Communication RS-232 Programmer’s Guide . . . i l f t l i Control Software for Windows i l f t l i . y l . r e VSC 75 Installation and Operation 2-12... -
Page 13: Rs-232 Programmer's Guide
Serial Communication Remote Control, cont’d The VSC 75 can be controlled by a host computer or other VSC error responses control device via an RS-232 connection with a protocol of When the VSC 75 receives a valid SIS command, it executes 9600 baud, 1 stop bit, no parity, and no flow control. -
Page 14: Command/Response Table
1B 7A 0D Reset to factory default Query firmware version number 51/71 Ver x.xx Display firmware version Request part number 4E/6E N60-321-01 Display VSC 75’s part # Display status Request information Command = 49/69 (see below) Response = • Frz • Exe... -
Page 15: Control Software For Windows
3-4 to 3-5. The control software is compatible with Windows 3.1/3.11, Windows 95/98 and Windows NT. The VSC 75 uses version 3.2 or higher of Extron’s VSC and DDS Control Program, which is included with the VSC 75. Installing the software The control program is contained on a single 3.5-inch... -
Page 16: Accessories
Remote Control, cont’d VSC 75 Appendix Specifications Part Numbers and Accessories Specifications Included Parts Accessories VSC 75 Serial Communication... - Page 17 Nominal level ....... 1V p-p Impedance ........75 ohms Sync Input type ........Autodetect RGBHV, RGBS, RGsB Standards ........NTSC 3.58, PAL Input level ........1.5V to 5V p-p Input impedance ......75 ohms VSC 75 Specifications VSC 75 Specifications...
-
Page 18: Included Parts
Accessories and Part Numbers Accessories and Part Numbers, cont’d Included Parts These items are included in each order for a VSC 75: Included parts Part number VSC 75 60-321-01 Mac-HV/VGA cable (6 feet) 26-462-01 S-video cable (6 feet) 26-316-02 VSC 75 user’s manual...
