Device Setup (

c )
The
Device setup
encoder or as a decoder.
NOTE:

Create Source (Encoder)

Select this option to create a source (ENCODER).
Source will be shown adjacent to a change device type button.
z
A videoport
z
Figure 17.
The Device Setup
Mode:
z
Enable — Normal operation; image transport is enabled.
z
Disable — Image transport is disabled.
z
Standby — Same as disable.
z
Identify — When checked, causes the name of the device to be overlaid on the content
z
that is presented on the SDI-OUT connector on the rear panel.
Data Interface — The selection defines which of the two network interfaces is to be
z
used for the data transport.
Multicast TTL — This value sets the Time To Live (TTL) for multicast packets.
z
d

Configuration (

)
The
Configuration
Click on an icon to access the configuration pages.
z
area allows a VN-Matrix 300 device to be configured as either an
The VN-Matrix 300 is available as a decoder (VND 300) only. In this case it is not
possible to configure the unit as an encoder.
and ancport icon will be created in the
Source (Encoder) Configuration and Setup
area provides access to the following controls and information.
area provides access to the device configuration pages.
Configuration
VN-Matrix 300 • System Configuration
window.
