Overview SNMP
—
The VN-Matrix 300 system has the ability to report alarm events via an SNMP trap, providing
simple integration with Network management systems (NMS).
When communicating using SNMP the VN-Matrix 300 complies with the requirements of
SNMP v3.
When generating SNMP traps the VN-Matrix 300 complies with the requirements of SNMPv1
and SNMPv2C.
Using SNMP
—
The SNMP password is the same as the administrator password. By default this is set to
admin
It is necessary to enter the administrator password in the accounts a page before SNMP can
be used. This process must be carried out for each of the following circumstances:
z
z
A password for SNMPv3 is required to be 8 characters long.
z
z

SNMP Trap Version

The VN-Matrix 300 supports both version 1 and version 2 SNMP traps (SNMPv1 and
SNMPv2c).

SNMP Community

The SNMP Community value acts as a password. It is used to authenticate messages
between the VN-Matrix 300 system and the NMS. By default the Community string is set to
public. The Community string must match that in use by the NMS; if not then it may not be
possible to manage the VN-Matrix 300 device.

SNMP Trap Destinations

The Filter Settings dialogue in the
IP addresses for NMS servers.
Figure 49.
The IP address of the NMS should be entered in the
Multiple destinations may be added.
Password
.
When first using the system
After a firmware upgrade to the system
If the
administrator password
characters are packed as follows:
admin becomes adminadm
If the
administrator password
concatenated:
becomes
concatenate concaten
Filter Settings Dialog Box
is less than 8 characters in length then the remaining
is longer than 8 characters then the value is
page is used to add and remove destination
Alarm Logs
Create Trap Destination
VN-Matrix 300 • Alarms and SNMP
box.
65
