Encoder Streams Panel

The
Streams
active streams that are configured on the encoder.
Stream definition — Provides information on any active streams from the Encoder.
z
Streams are provisioned at the display (decoder) device.
z
Once a stream has been provisioned the details will appear in the listing.
z
RTP UNICAST Streams
When the multicast option is not selected, a decoder may connect using either:
TCP/IP connection — Used for guaranteed delivery on point to point (single connection)
z
systems.
RTP UNICAST connection — Streams are sent as RTP Unicast.
z
NOTE:
Configuring a Multicast Connection
When the
multicast connection.
The user is prompted to enter a Multicast group address in the range 224.nnn.nnn.nnn
z
to 239.nnn.nnn.nnn.
Streams are sent as RTP Multicast.
z
Note that the VN-Matrix 300 supports IGMP V2 for multicast working.
z
New export stream
This function is not supported.
panel of the
Configure
In this mode, up to 4 simultaneous streams are supported. This is
dependant on the total aggregated bit rate – which must not exceed
270 Mbs.
enable option (see figure 19) is selected, the user may configure a
Multicast
page for an encoder provides information on any
VN-Matrix 300 • System Configuration 33
