Extron electronics VN-Matrix 300 User Manual page 61

2.
Click the Upload button to begin uploading the file to the VN-Matrix 300 controller.
This may take a few minutes.
Once the file is uploaded, you can begin installing it into each unit , starting with the
controller unit.
1. From the
Device List
upgrade.
2. From the page click the
Device
3.
Click the
Select Firmware Version
want to install. Usually there will only be one file listed.
The remainder of the installation procedure is achieved using the
buttons, to move the installation between the various stages. The current stage/
reverse
status is indicated by the Device Upgrade Status
The process allows you to temporarily install and test the new firmware and, if everything is
OK, you can then permanently install (commit) the new firmware. Up until the last stage it is
possible to return to the existing firmware version.
Figure 40.
Temporarily, Testing, and Permanently Installing New Software
1.
Click the button. The
forward
percentage progress. This stage may last a few minutes.
TIP: The chosen firmware version is confirmed in the Upgrade Version field.
2.
When
READY TO ACTIVATE
3. The unit will then reboot.
Once rebooted the
Device Upgrade Status
the VN-Matrix 300 will be using the new firmware. Test for correct operation.
4. If everything is working correctly, click forward again to permanently install the new
firmware.
The Device Upgrade Status
stage may last a few minutes.
If you experience any problems, click
5. When the Device Upgrade Status field returns to
VN-Matrix 300 • Firmware, License Upgrades, and User Accounts
page, click on the VN-Matrix 300 unit that you want to
tab. The
Upgrade Upgrade
listbox and choose the new firmware file you
field.
Device Upgrade Status
appears, click the
forward
field will show
field shows Committing
to return to the previous stage.
reverse
WAIT
page will appear.
and (if necessary)
forward
field will show
PREPARE
button again.
and
READY TO COMMIT
and percentage progress. This
the unit is ready for use.
and
55
