Installation
and Basic Setup
Procedures
This section describes basic installation and setup procedures, including:
z
z
z
z
z
z
z
z

Choosing a Suitable Location

The VN-Matrix 300 is designed to be used either as a free-standing unit or to be mounted in
a 19-inch equipment rack using the optional kits available.
CAUTION: Whichever installation method you choose there are certain environmental

Environmental Requirements

CAUTION: The criteria on this page must be observed for all installations of the

Orientation

The VN-Matrix 300 is designed to be used free-standing on a stable, horizontal surface. It
can, however, be used in any orientation subject to the necessary ventilation requirements.
Choosing a Suitable Location
Environmental Requirements
Rack Mount Requirements
Mains Power Connection
Mains Power Cord
Accessories
Setup Procedure
Network Connections
requirements, detailed on the following pages, which must be observed in
order to ensure safe and reliable operation.
VN-Matrix 300, whether free-standing or rack-mounted.
VN-Matrix 300 • Installation and Basic Setup Procedures 11
