Licensing

Each VN-Matrix 300 unit is supplied with a feature set that is defined by a license key and a
structure. This is not intended to be changed as part of normal operation and this section is
provided for information only.
Figure 41.
License structure
The licensed features are represented in the by the structure. The characters used in the
structure and their meaning are outlined below.
NOTES:
Character String
mA
mH
oS
oD
License Page
This information is provided for interest only; it is not essential for a user to be
•
familiar with this.
As the range of licensed features increases, additional characters will be added
•
that may not appear in the list presented here.
Representing
V Number of supported video (encoder) channels
D Number of supported display (decoder) channels
N Enables ancillary channel support.
Internal use – not user option
Internal use – not user option
Internal use – not user option
Internal use – not user option
S
Supported video transports (SDI, HDSDI, 3GSDI)
U
Number of supported audio (ancillary) channels
VN-Matrix 300 • Firmware, License Upgrades, and User Accounts 56
