Network (NIC) Connections

All network connections are made at the rear panel of the VN-Matrix 300.
CAUTION: Do not proceed with connecting VN-Matrix 300 to an existing network until
Typically, the VN-Matrix 300 will connect to convenient network point on an existing in-
house network. Use the correct cable type for your chosen network.

Single Network Connection

The VN-Matrix 300 may be configured to run on a single physical network port (1 or 2). In
this configuration all data (image, ancillary and control including monitoring) is transported
over a single physical link.
The VN-Matrix 300 may be used over both switched (single segment) and routed
(multi-segment) networks.

Dual Network Connection

If required, both network connections may be used. In this configuration image and ancillary
data is transported on one connection whilst the other network port is used for monitoring
and or management functions.

System Control Data

System control is managed by the VN-Matrix 300 that has been designated as the controller.
Any changes made in the interface are sent to the affected VN-Matrix 300 device from the
controller. The control information between the controller and any other VN-Matrix 300 unit
in the system is sent via the network that has been assigned to the controller.
Function Comment
Set the number of the By default this is set to 5432, this may be changed if required.
port that is used for Note that all VN-Matrix 300 units MUST have the same port
communications with number assigned.
the system controller.
Set the port number By default this is set to 80, this may be changed if required.
that is used for Note that the browser in use must use the same port number.
communication with
the server.
Reboot and activate Any changes made are only activated after a reboot of the
settings. VN-Matrix 300 unit.
NOTE:
it is correctly configured using the
Incorrect connection or configuration may cause disruption to other
network users.
VN-Matrix 300 • Installation and Basic Setup Procedures
Typing reboot at the hyperterminal
cursor will also reset the unit.
Low level configuration
procedure.
