Unfused Plugs or Hard-wired
If the power cord is fitted with an unfused plug, or is hard-wired into a power strip (mains
distribution batten), then the power cord must be protected by an external fuse or circuit
breaker of a rating shown in the table below:
Supply Voltage
Maximum Fuse Rating
Minimum Fuse Rating
WARNING:

Accessories

Supplied Accessories

In addition to this User Guide, the VN-Matrix 300 is supplied with the following accessories.
Item
12 V Power Supply Unit (PSU)
RS-232 Serial cable
If any of these items is missing or damaged, please contact your Extron representative
immediately.

Optional Accessories

The following optional accessories are also available for use with the VN-Matrix 300 — these
must be ordered separately from your Extron dealer:
Item
VNM Dual Rack Mount Kit
(1U, Dual mounting)
VNM Quad Rack Mount Kit
(2U, Quad mounting)
VNM MBU
VNM 12 PSDR
Extron faceplate
110V nominal 230V nominal
10A
3A
Never attempt to fit a fuse or circuit breaker of a higher maximum rating
than shown above.
Quantity
1
1
Description
A kit that allows 2 VN-Matrix 300 units to
be installed in a 19 inch equipment rack. Full
instructions are included with the kit.
A kit that allows 4 VN-Matrix 300 units to be
installed, side by side, in a 19 inch equipment
rack. Full instructions are included with the
kit.
A kit that allows a VN-Matrix 300 unit to be
mounted to any convenient flat surface, such
as under a desk. Full instructions are included
with the kit.
A 12 way redundant power supply system,
for use when rack mounting multiple units.
VN-Matrix 300 • Installation and Basic Setup Procedures
10A
3A
Part Number
70-761-01
27-699-01LF
Part Number
60-1130-01
60-1131-01
60-1132-01
70-762-01
60-1129-01
15
