Chapter 2: Jumpers and Connectors

Panel Backlight Connector

Connector type: 1x7 7-pin header JST, 2.5mm pitch
Connector location: J7
7 1
Pin Definition
1 VCC5
2 12V
3 12V
4 BKCTRL
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
5 GND
6 GND
7 BKLEN

Touch Sensor Connector

Connector type: 1x5 5-pin header JST, 2.5mm pitch
Connector location: J9
5 1
Pin 4-wire
1 Left
2 Top
3 N/A
4 Right
5 Bottom
39
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
5-wire
LL (L)
UL (Y)
Sense (S)
LR (X)
UR (H)
